Switch Dgs-3630-52tc/sie 52-port Layer 3 Stackable Managed Gigabit
ITCurry #: 12135195 | Article #: DGS-3630-52TC/SI/E-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The DGS-3630 Series Gigabit L3 Stackable Managed Switches are a range of switches designed for Small to Medium Businesses (SMBs), Small to Medium Enterprises (SMEs), enterprises and ISPs. With Gigabit Ethernet SFP, 10 GbE SFP+, security features, and advanced Quality of Service (QoS), the DGS-3630 Series can act as core, distribution or access layer switches.
Stackable Managed Switches
- Designed for Small to Medium Businesses, Enterprises and ISPs
- Deliver high performance, flexibility, fault tolerance, and advanced software features
- Gigabit Ethernet SFP, 10 GbE SFP+, security features, and advanced Quality of Service (QoS), the DGS-3630 Series can act as core, distribution or access layer switches
- High port densities, switch stacking, and easy management make the DGS-3630 Series suitable for a variety of applications
- DGS-3630-28PC and DGS-3630-52PC feature Power over Ethernet, which allows PoE-powered devices to be powered by the switch through a standard Ethernet cable.
Outperforming the competition
The DGS-3630-28TC was benchmarked against a market leading competitor's device. It matched or exceeded the competitor's performance across all tests despite being significantly lower in price with a much lower power consumption.
Versatile Management
The DGS-3630 Series provides:
- Network Assistant Utility
- Industry-standard CLI
- Intuitive web-based management interface
Support for SNMP allows centralized management of a large number of devices and out-of-band management is available via a dedicated console port.
A mini-USB console port allows the DGS-3630 Series to be managed without any extra connectors, and a USB Type A port can be used to store logs, configuration, and firmware images.
High Availability and Flexibility
Includes stacking technology, which allows multiple switches to be combined to form a single physical or virtual stack.
Scale your network using just a stacking cable and without the need for stacking modules.
Increased redundancy over multiple physical units, simplifies management and provides a single IP address to manage all members in the stack.
Security, Performance & Availability
Robust set of QoS features helps ensure that critical network services such as Voice over IP and video conferencing are given high priority through the network.
The D-Link Safeguard Engine increases the switch’s reliability, serviceability, and availability by preventing malicious flooding traffic caused by worms or virus attacks.
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L3 |
| Quality of Service (QoS) | Ja |
| Web-gebaseerd management | Ja |
| Traffic-classificatie | Ja |
| ARP-inspectie | Ja |
| System event log | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 44 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Aantal Gigabit Ethernet (koper)-poorten | 44 |
| Aantal Combo SFP-poorten | 4 |
| Aantal moduleslots SPF+ | 4 |
| Console port | RJ-45/Mini-USB |
| Aantal USB 2.0-poorten | 1 |
| Netstekker | AC-in-aansluiting |
| Netwerk | |
| Netwerkstandaard | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qbb, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Ja |
| Koperen ethernetbekabelingstechnologie | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring | Ja |
| Full duplex | Ja |
| Routing entries | 16000 |
| Datastroombeheer | Ja |
| Verbindingsaggregatie | Ja |
| Broadcast stormbeheer | Ja |
| Spanning tree protocol | Ja |
| Ethernet Ring Protection Switching (ERPS) | Ja |
| VLAN=ondersteuning | Ja |
| Virtuele LAN-functies | IP subnet-based VLAN, MAC address-based VLAN, MVRP, Multicast VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, Voice VLAN |
| Aantal VLANs | 4094 |
| Data-uitwisseling | |
| Switchingcapaciteit | 176 Gbit/s |
| Verzending snelheid | 130,95 Mpps |
| MAC-adrestabel | 68000 entries |
| Aantal wachtrijen | 8 |
| Statische route | Ja |
| Aantal statische routes | 512 |
| Aantal IP-interfaces | 256 |
| Jumbo Frames ondersteuning | Ja |
| Jumbo frames | 12000 |
| Packet buffergeheugen | 4 MB |
| Beveiliging | |
| DHCP-functies | DHCP auto-config, DHCP client, DHCP guarding, DHCP relay, DHCP server, DHCP snooping |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
| Ondersteunde beveiligingsalgoritmen | 802.1x RADIUS, SSH, SSH-2, SSL/TLS |
| MAC adres filtering | Ja |
| SSH/SSL support | Ja |
| Bescherming lus | Ja |
| BPDU filtering / bescherming | Ja |
| Authenticatie | Gast-VLAN, Poortgebaseerde authenticatie |
| Root-bescherming | Ja |
| Authenticatie type | IEEE 802.1x |
| Algoritmen wachtrijplanning | SP, WRR+SP, Weighted Round Robin (WRR), Weighted random early detection (WRED) |
| Multicast-functies | |
| Multicast-ondersteuning | Ja |
| Multicast Listener Discovery (MLD) snooping | Y |
| Protocollen | |
| Beheerprotocollen | SNMP, NTPv3/v4, Telnet |
| Routing protocols | BGP4, OSPFv3, RIP, RIP-1, RIP-2, RIPng, VRRP |
| IP Source Guard (IPSG) | Ja |
| Design | |
| Rack-montage | Ja |
| Stapelbaar | Ja |
| Vormfactor | 1U |
| Kleur van het product | Zwart |
| LED-indicatoren | Ja |
| Aantal ventilatoren | 2 ventilator(en) |
| Veiligheid | cUL, CB, CE, CCC, BSM |
| Elektromagnetische compatibiliteit | CE, FCC Class A, C-Tick, VCCI, BSMI, CCC |
| Prestatie | |
| Virtual stacking (units) | 32 |
| Geluidsniveau | 53,9 dB |
| Dying Gasp | Ja |
| Mean time between failures (MTBF) | 263936,78 uur |
| Energie | |
| Stroombron | AC |
| Vermogenstoevoer inclusief | Ja |
| Redundante voeding | Ja |
| Aantal voedingen | 1 |
| AC-ingangsspanning | 100 - 240 V |
| Vermogensverbruik (max) | 62 W |
| Spanningsbeveiliging | Ja |
| Overspanningsbeveiliging in voltage | 6 kV |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -5 - 50 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 95 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Warmtedissipatie | 212 BTU/h |
| Gewicht en omvang | |
| Breedte | 441 mm |
| Diepte | 259,8 mm |
| Hoogte | 44 mm |
| Gewicht | 4,04 kg |
| Verpakking | |
| Breedte verpakking | 538 mm |
| Diepte verpakking | 560 mm |
| Hoogte verpakking | 170 mm |
| Gewicht verpakking | 5,55 kg |
| Certificaten | |
| Certificaten van naleving | BSMI, CCC, CE, Federal Communications Commission (FCC), RoHS, VCCI |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
