Outperforming the competition
The DGS-3630-28TC was benchmarked against a market leading competitor's device. It matched or exceeded the competitor's performance across all tests despite being significantly lower in price with a much lower power consumption.
Versatile Management
The DGS-3630 Series provides:
- Network Assistant Utility
- Industry-standard CLI
- Intuitive web-based management interface
Support for SNMP allows centralized management of a large number of devices and out-of-band management is available via a dedicated console port.
A mini-USB console port allows the DGS-3630 Series to be managed without any extra connectors, and a USB Type A port can be used to store logs, configuration, and firmware images.
High Availability and Flexibility
Includes stacking technology, which allows multiple switches to be combined to form a single physical or virtual stack.
Scale your network using just a stacking cable and without the need for stacking modules.
Increased redundancy over multiple physical units, simplifies management and provides a single IP address to manage all members in the stack.
Security, Performance & Availability
Robust set of QoS features helps ensure that critical network services such as Voice over IP and video conferencing are given high priority through the network.
The D-Link Safeguard Engine increases the switch’s reliability, serviceability, and availability by preventing malicious flooding traffic caused by worms or virus attacks.
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L3 |
| Quality of Service (QoS) | Ja |
| Web-gebaseerd management | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 20 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Aantal Combo SFP-poorten | 4 |
| Aantal moduleslots SPF+ | 4 |
| Vezel-optische connector | SFP+ |
| Console port | RJ-45/Mini-USB |
| Aantal USB 2.0-poorten | 1 |
| Netwerk | |
| Netwerkstandaard | IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Qbb, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3ah, IEEE 802.3at |
| 10G support | Ja |
| Koperen ethernetbekabelingstechnologie | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Port mirroring | Ja |
| Full duplex | Ja |
| IP routing | Ja |
| Routing entries | 16000 |
| Datastroombeheer | Ja |
| Verbindingsaggregatie | Ja |
| Head-of-line (HOL) blocking | Ja |
| Auto-negotiation | Ja |
| Ethernet Ring Protection Switching (ERPS) | Ja |
| VLAN=ondersteuning | Ja |
| Virtuele LAN-functies | Private VLAN, Voice VLAN, Protocol-based VLAN, MAC address-based VLAN, Port-based VLAN |
| Aantal VLANs | 4000 |
| Data-uitwisseling | |
| Switchingcapaciteit | 128 Gbit/s |
| Verzending snelheid | 95,24 Mpps |
| MAC-adrestabel | 68000 entries |
| Store-and-forward | Ja |
| Statische route | Ja |
| Aantal statische routes | 512 |
| Jumbo Frames ondersteuning | Ja |
| Jumbo frames | 12000 |
| Packet buffergeheugen | 4 MB |
| Beveiliging | |
| DHCP-functies | DHCP server, DHCP client |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
| Ondersteunde beveiligingsalgoritmen | 802.1x RADIUS, SNMP, SNMPv3, SSH, SSL/TLS |
| SSH/SSL support | Ja |
| Bescherming lus | Ja |
| BPDU filtering / bescherming | Ja |
| IP-MAC-Port binding | Ja |
| Multicast-functies | |
| Multicast-ondersteuning | Ja |
| Multicast Listener Discovery (MLD) snooping | MLD v1, MLD v2 |
| Design | |
| Rack-montage | Ja |
| Stapelbaar | Ja |
| Kleur van het product | Zwart, Grijs |
| Aantal ventilatoren | 4 ventilator(en) |
| Veiligheid | cUL, CB, CE, CCC, BSMI |
| Elektromagnetische compatibiliteit | CE, FCC A, C-Tick, VCCI, BSMI, CCC |
| Prestatie | |
| Physical stacking (units) | 9 |
| Virtual stacking (units) | 32 |
| Type processor | Ja |
| Energie | |
| Stroombron | AC/DC |
| Redundante voeding | Ja |
| AC-ingangsspanning | 100 - 240 V |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Ja |
| Aantal Power over Ethernet plus (PoE +)-poorten | 24 |
| Vermogen per poort Power over Ethernet (PoE) | 30 W |
| Totaal Power over Ethernet (PoE)-budget | 370 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -5 - 50 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 10 - 95 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Gewicht en omvang | |
| Breedte | 441 mm |
| Diepte | 380 mm |
| Hoogte | 44 mm |
| Gewicht | 5,88 kg |
| Technische details | |
| (Binnenste) verzendverpakking hoogte | 57,2 cm |
| (Binnenste) verzendverpakking breedte | 36,2 cm |
| (Binnenste) verzendverpakking lengte | 57,9 cm |
| Nettogewicht transportverpakking | 12,9 kg |
| Producten per (binnenste) verzendverpakking | 2 stuk(s) |
| Pallet brutogewicht (lucht) | 342,4 kg |
| Aantal dozen per pallet (lucht) | 18 stuk(s) |
| Aantal per pallet (lucht) | 36 stuk(s) |
| Pallet brutolengte | 110 cm |
| Pallet brutobreedte | 120 cm |
| Pallethoogte (lucht) | 185,1 cm |
| Pallet brutogewicht (zee) | 342,4 kg |
| Aantal dozen per pallet (zee) | 18 stuk(s) |
| Producten per pallet (zee) | 36 stuk(s) |
| Pallethoogte (zee) | 185,1 cm |
| (Binnenste) verzendverpakking gewicht | 18 kg |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
