4x2 HDMI Matrix / Multi-Viewer. 4K/30Hz SPDIF. Stereo. RS232
ITCurry #: M9239327 | Article #: DS-55345-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
Switch conveniently between up to 4 HDMI sources and 2 playback devices, and distribute your media content independently / Multi-viewer offers 6 modes for individual display of sources (split-screen, PIP)
- Switch between up to 4 HDMI sources and 2 playback devices via remote control, on the device itself or via RS232 control
- Multi-viewer: 6 modes for individual display of sources at HDMI output A (primary) or at HDMI output A & B simultaneously (secondary) via remote control or on the device itself
- Audio extractor: Toslink / Stereo (3.5 mm) - Decoupling / separate reproduction of the audio signal
- Max. resolution: 4K/30 Hz
- RS232 control via micro USB
- Scaler (changeover switch) - Adjustment of HDMI output resolution (1080p, 1600p, 4K/30Hz)
- Separate on/off switch
- Video bandwidth: 10.2 Gbps
- HDCP 1.4
- HDMI 1.4
The DIGITUS® 4x2 HDMI Matrix Switch / Quad Multi-Viewer enables you to switch conveniently between up to 4 HDMI sources and 2 playback devices, and distribute your media content independently. Switch conveniently between the signal sources via remote control, on the device itself or via RS232 control. The multi-viewer function offers 6 modes for individual display of sources (split-screen, PIP) at output A or parallel at A & B. Audio signals can also be decoupled and separately reproduced via Toslink or 3.5 mm stereo connection. Supports resolutions of up to 4K/30Hz. The HDMI output resolution can be adjusted individually using a scaler.
| Kenmerken | |
| Type product | AV-matrixschakelaar |
| Bandbreedte | 10,2 Gbit/s |
| HDCP | Ja |
| HDCP versie | 1.4 |
| Design | |
| Kleur behuizing | Zwart |
| Materiaal behuizing | Metaal |
| Soort bediening | Knoppen, Afstandsbediening |
| Aan/uitschakelaar | Ja |
| LED-indicatoren | Status |
| Afstandsbediening inbegrepen | Ja |
| Beeldscherm | |
| Ingebouwd display | Nee |
| Poorten & interfaces | |
| Aantal HDMI-invoerpoorten | 4 |
| Aantal HDMI-uitvoerpoorten | 2 |
| HDMI versie | 1.4 |
| USB-connectortype | Micro-USB A |
| Type aansluitplug | 3,5 mm |
| Hoofdtelefoonuitgangen | 1 |
| Aansluiting voor netstroomadapter | Ja |
| Energie | |
| Stroomverbruik (typisch) | 5 W |
| Output current | 1000 mA |
| Spanning | 5 V |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 70 øC |
| Gewicht en omvang | |
| Breedte | 91 mm |
| Diepte | 214 mm |
| Hoogte | 18,5 mm |
| Gewicht | 450 g |
| Breedte verpakking | 238 mm |
| Diepte verpakking | 292 mm |
| Hoogte verpakking | 55 mm |
| Gewicht verpakking | 18 kg |
| Inhoud van de verpakking | |
| Snelstartgids | Ja |
| Inclusief AC-adapter | Ja |
| Inclusief IR-ontvanger | Ja |
| Warranty | |
| Base Warranty | Non Non |
