4-port USB True 4k DisplayPort KVM Switch With USB 3.0
ITCurry #: 90314309 | Article #: CS1924ATC-AT-G-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The ATEN CS1924ATC 4 Port USB 3.0 4K DisplayPort KVMP™ Switch for ATC is tailor-made for Air Traffic Control scenarios. It supports 2Kx2K resolution, making it perfect for radar monitoring, and also enables constant monitoring of flight information and mission-critical processes.
The Zero-Second Switch function ensures nearly real-time switching without any black screens, providing air traffic controllers instant access to four USB / DisplayPort-interfaced ATC computers for crucial operations. Port switching is flexible via pushbuttons, hotkeys, mouse, RS-232 commands, or an optional accessory the remote port selector.
With two lockable DC jacks for power redundancy, the CS1924ATC ensures uninterrupted operation and constant availability for mission-critical applications. It aims to greatly minimize or eliminate the risk of downtime.
Patented ATEN technology – Video DynaSync™, and EDID expert™ , combined with DisplayPort 1.2 and video resolutions up to 4K @ 60 Hz, it delivers optimized display resolution with exceptional detail and clarity in all conditions.
The CS1924ATC creates a safer environment and enhanced operational efficiency for Air Traffic Control Towers, Approach Control Rooms, and Area Control Centers, specifically tailored the air traffic control industry.
| Poorten & interfaces | |
| Aantal computers | 4 |
| Aansluiting toetsenbord | USB |
| Aansluiting muis | USB |
| Aansluiting video | DisplayPort |
| Aantal DisplayPorts | 5 |
| Console-poorten | 3.5mm hoofdtelefoon, 3.5mm mic, DisplayPort, USB A, VGA (D-Sub) |
| Aantal USB-poorten console | 2 |
| Aantal Console DisplayPorts-poorten | 1 |
| USB-hub | Ja |
| Aantal USB 3.2-hubpoorten type A (3.1 Gen 1) | 6 |
| USB-connectortype | Micro-USB, USB Type-A |
| Audio-aansluitingen | Ja |
| Hoofdtelefoonuitgangen | 6 |
| Aantal microfooningangen | 6 |
| RJ-11 ports kwantiteit | 1 |
| Aansluiting voor netstroomadapter | Ja |
| Prestatie | |
| HD type | 4K Ultra HD |
| Maximum resolutie | 4096 x 2160 Pixels |
| Videobandbreedte | 60 Hz |
| Upgraden van firmware mogelijk | Ja |
| Design | |
| Kleur van het product | Zwart |
| Materiaal behuizing | Metaal |
| LED-indicatoren | Ja |
| drukknop | Ja |
| Sneltoetsen | Ja |
| Beeldscherm | |
| Ingebouwd display | Ja |
| Energie | |
| Stroombron | DC |
| Ingangsspanning | 12 V |
| Stroomverbruik (typisch) | 16,84 W |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 20 øC |
| Temperatuur bij opslag | -20 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 80 procent |
| Gewicht en omvang | |
| Breedte | 161 mm |
| Diepte | 335 mm |
| Hoogte | 65,5 mm |
| Gewicht | 1,88 kg |
| Logistieke gegevens | |
| Land van herkomst | Taiwan |
| Warranty | |
| Base Warranty | Non Non |
