Smart UPS Xl 3000va 120v Tower/rack Convertible
ITCurry #: 02808145 | Article #: SUA3000XL-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Cold-start capable
Provides temporary battery power when the utility power is out.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.
| Features | |
| Output power capacity | 3 kVA |
| Output power | 2700 W |
| Input frequency | 50/60 Hz |
| Emergency Power Off (EPO) | Y |
| Noise level | 53 dB |
| Audible alarm(s) | Y |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Typical backup time at full load | 5 min |
| Typical backup time at half load | 17 min |
| Battery recharge time | 3 h |
| Design | |
| Cable length | 2.44 m |
| Product colour | Black |
| Certification | CSA,FCC Part 15 Class A,UL 1778, RoHS 7b Exemption |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -15 - 45 øC |
| Weight & dimensions | |
| Weight | 63.6 kg |
| Other features | |
| Interface | DB-9 RS-232, Smart-Slot |
| Output connections | 9x NEMA 5-15R 2x NEMA 5-20R |
| Input connection type | NEMA L5-30P |
| Dimensions (WxDxH) | 221 x 495 x 444 mm |
| Nominal output voltage | 120 V |
| Nominal input voltage | 120 V |
| Warranty | |
| Base Warranty | Non Non |
