Output Power
Capacity
|
2700 Watts
/ 3000 VA
|
Nominal Output
Voltage
|
120V
|
Efficiency at Full
Load
|
95%
|
Output Voltage
Distortion
|
Less than 5% at full
load
|
Output Frequency
(sync to mains)
|
47 - 53 Hz for 50 Hz
nominal,57 - 63 Hz for 60 Hz nominal
|
Crest
Factor
|
up to 5 : 1
|
Waveform
Type
|
Sine wave
|
Output
Connections
|
(6) NEMA 5-15R
(2) NEMA 5-20R
|
Nominal Input
Voltage
|
120V
|
Input
Frequency
|
50/60 Hz +/- 3 Hz (auto
sensing)
|
Input
Connections
|
NEMA L5-30P
|
Cord
Length
|
8 feet (
2.44 meters)
|
Input voltage range
for main operations
|
82 - 144V
|
Input voltage
adjustable range for mains operation
|
75 - 154V
|
Battery
Type
|
Maintenance-free sealed
Lead-Acid battery with suspended electrolyte :
leakproof
|
Typical recharge
time
|
3 hour(s)
|
RBC
Quantity
|
1
|
Typical Backup Time
at Half Load
|
11.3 minutes (1350
Watts)
|
Typical Backup Time
at Full Load
|
3.0 minutes (2700
Watts)
|
nterface
Port(s)
|
DB-9
RS-232,SmartSlot,USB
|
Available SmartSlot
Interface Quantity
|
1
|
Control
panel
|
LED status display with
load and battery bar-graphs and On Line : On Battery
: Replace Battery : and Overload Indicators
|
Audible
Alarm
|
Alarm when on battery :
distinctive low battery alarm : configurable
delays
|
Emergency Power Off
(EPO)
|
Yes
|
Surge energy
rating
|
480 Joules
|
Filtering
|
Full time multi-pole
noise filtering : 0.3% IEEE surge let-through : zero
clamping response time : meets UL 1449
|
Maximum
Height
|
3.50 inches (
89 mm)
|
Maximum
Width
|
19.00 inches
(483 mm)
|
Maximum
depth
|
26.00 inches
(660 mm)
|
Rack
Height
|
2U
|
Net Weight
|
96.00 lbs. (
43.64 kg)
|
Color
|
Black
|
Operating
Environment
|
0 - 40 °C (32
- 104 °F)
|
Operating Relative
Humidity
|
0 - 95%
|
Operating
Elevation
|
0-10000 feet
(0-3000 meters)
|
Storage
Temperature
|
-15 - 45 °C (5
- 113 °F)
|
Storage Relative
Humidity
|
0 - 95%
|
Storage
Elevation
|
0-50000 feet
(0-15000 meters)
|
Audible noise at 1
meter from surface of unit
|
47 dBA
|
Online Thermal
Dissipation
|
400 BTU/hr
|
Regulatory
Approvals
|
BSMI,CSA,UL 1449,UL
1778,FCC Part 15 Class A
|
