Cubi 5 10m 062eu Black - i5 10210u - 8GB Ram - 512GB SSD - Win10 Pro
ITCurry #: 86328414 | Article #: CUBI 5 10M-062EU-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
IDEAL FOR COUNTLESS APPLICATIONS
The MSI Cubi 5 is a small and powerful mini-desktop. It is suited to serve as HTPC at home, all-around media PC at home, at the office or for any commercial project.
FREE FROM LIMITATIONS
Intel® Core™ i7 processor (Comet Lake), delivering computing capability which will keep you in the flow, wherever you go.
HAND PALM-SIZED PC
MSI Cubi 5 is the smallest mini PC in its kind. With a 0.66 liter case that still provides all the elements of a desktop-worthy PC.
MOUNTABLE TO A MONITOR
Cubi 5 is designed with a mini size and supports standard VESA-mount. Mount the Cubi 5 to the back of a monitor and make the PC completely invisible.
SUPPORT EXTERNAL POWER SWITCH
Making Power Computer much easier. Cubi 5 is designed to support external power switch.
Located computer in a hard to reach area , this is a convenient switch on the desk and hitting it rather than bend down to turn the computer on.
EASY TO UPGRADE
Only remove 4 screws at the bottom cover to gain access and replace the M.2 SSD, memory modules and 2.5” HDD/SSD storage slots. It’s just that simple.
QUIET, ENERGY-EFFICIENT DESIGN
MSI Cubi 5 has an excellent thermal design and low noise fan, resulting in a low noise level of only 23.6 dB of idle mode.
USB 3.2 GEN 1 TYPE-C WITH REVERSIBLE DESIGN
Get all the performance benefits from USB 3.2 Gen1 combined with the convenience of the USB Type-C connector. This reversible connector allows for effortless connecting of USB devices.
DO MORE WORK SIMULTANEOUSLY
Are you watching a lot of webpages and applications on a small monitor? With the HDMI and DP ports,MSI Cubi 5 can support dual monitors, you can do and view more.
| Processor | |
| Processorfabrikant | Intel |
| Processorfamilie | Intel© CoreT i5 |
| Processorgeneratie | Intel© 10de generatie CoreT i5 |
| Processormodel | i5-10210U |
| Aantal processorkernen | 4 |
| Processor aantal threads | 8 |
| Maximale turbofrequentie van processor | 4,2 GHz |
| Frequentie van processor | 1,6 GHz |
| Processor socket | BGA 1528 |
| Processor cache | 6 MB |
| Systeembus | 4 GT/s |
| Processor lithografie | 14 nm |
| Processor operating modes | 64-bit |
| Codenaam processor | Comet Lake |
| Thermal Design Power (TDP) | 15 W |
| Configureerbare TDP-upfrequentie | 2,1 GHz |
| Configureerbare TDP-up | 25 W |
| Configureerbare TDP-down | 10 W |
| Configureerbare TDP-downfrequentie | 0,8 GHz |
| Tjunction | 100 øC |
| PCI Express slots versie | 3.0 |
| Maximaal aantal PCI Express-lijnen | 16 |
| PCI Express configuraties | 1x4, 2x2, 1x2+2x1, 4x1 |
| Maximaal intern geheugen ondersteund door processor | 64 GB |
| Geheugentypen ondersteund door processor | DDR4-SDRAM, LPDDR3-SDRAM |
| Klokgeheugen-snelheden ondersteund door processor | 2666,2133 MHz |
| Geheugenbandbreedte ondersteund door de processor ( max) | 41,66 GB/s |
| Geheugen | |
| Intern geheugen | 8 GB |
| Maximum intern geheugen | 64 GB |
| Intern geheugentype | DDR4-SDRAM |
| Geheugenlayout | 1 x 8 GB |
| Geheugenslots | 2x SO-DIMM |
| Opslagmedia | |
| Totale opslagcapaciteit | 512 GB |
| Opslagmedia | SSD |
| Soort optische drive | Nee |
| Totale capaciteit SSD's | 512 GB |
| Aantal ge‹nstalleerde SSD's | 1 |
| SSD capaciteit | 512 GB |
| SSD interfaces | PCI Express |
| SSD-vormfactor | M.2 |
| Ge‹ntegreerde geheugenkaartlezer | Nee |
| Grafisch | |
| Aparte grafische adapter | Nee |
| Ingebouwde grafische adapter | Ja |
| Discreet grafische adapter model | Niet beschikbaar |
| Interne-GPU-fabrikant | Intel |
| On-board graphics adapter model | Intel© UHD Graphics |
| Basisfrequentie ingebouwde grafische adapter | 300 MHz |
| Graphics on-board -adapter dynamische frequentie (max) | 1100 MHz |
| Maximaal geheugen ingebouwde grafische adapter | 32 GB |
| Aantal displays ondersteund (door on-board grafische adapter) | 3 |
| On-board grafische adapter DirectX-versie | 12.0 |
| On-board grafische adapter OpenGL versie | 4.5 |
| On-board grafische adapter ID | 0x9B41 |
| Aantal verwerkingseenheden | 24 |
| Netwerk | |
| Ethernet LAN | Ja |
| Ethernet LAN, data-overdrachtsnelheden | 10,100,1000 Mbit/s |
| Wifi | Ja |
| Wifi-standaard | Wi-Fi 6 (802.11ax) |
| Wi-Fi-standaarden | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Bluetooth | Ja |
| Poorten & interfaces | |
| Aantal USB 2.0-poorten | 2 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 3 |
| Aantal poortenUSB 3.2 Gen 1 (3.1 Gen 1) Type C | 1 |
| DVI-poort | Nee |
| Aantal HDMI-poorten | 1 |
| HDMI versie | 1.4 |
| Aantal DisplayPorts | 1 |
| DisplayPort versie | 1.2 |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Microfoon, line-in ingang | Ja |
| Hoofdtelefoonuitgangen | 1 |
| Aansluiting voor netstroomadapter | Ja |
| Design | |
| Type behuizing | Mini PC |
| Ondersteuning voor plaatsing | Horizontaal |
| Bevestigingsmogelijkheid voor kabelslot | Ja |
| Kabelslot sleuf type | Kensington |
| Kleur van het product | Zwart |
| Prestatie | |
| Markt positionering | Bedrijf |
| Audiochip | Realtek ALC887 |
| Audio-uitgangskanalen | 2.1 kanalen |
| Type product | Mini PC |
| Software | |
| Inclusief besturingssysteem | Windows 10 Pro |
| Architectuur besturingssysteem | 64-bit |
| Processor speciale functies | |
| Intel© 64 | Ja |
| Enhanced Intel SpeedStep Technology | Ja |
| Ingebouwde opties beschikbaar | Nee |
| Intel© Clear Video HD Technology (Intel© CVT HD) | Ja |
| Intel© Clear Video-technologie | Ja |
| Intel© VT-x with Extended Page Tables (EPT) | Ja |
| Intel© TSX-NI | Nee |
| Idle States | Ja |
| Thermal Monitoring Technologies | Ja |
| Intel© Stable Image Platform Program (SIPP) | Nee |
| Intel© AES New Instructions (Intel© AES-NI) | Ja |
| Intel© Secure Key | Ja |
| Intel© OS Guard | Ja |
| Intel© Trusted Execution Technology | Nee |
| Execute Disable Bit | Ja |
| Intel© Flex Memory Access | Ja |
| Intel© Software Guard Extensions (Intel© SGX) | Ja |
| Verpakkingsgrootte processor | 46 x 24 mm |
| Ondersteunde instructie sets | SSE4.1, SSE4.2, AVX 2.0 |
| CPU configuratie (max) | 1 |
| Intel© Virtualization Technology for Directed I/O (VT-d) | Ja |
| Intel© Virtualization Technology (VT-x) | Ja |
| ARK ID processor | 195436 |
| Intel© Turbo Boost Technology | 2.0 |
| Intel© Hyper Threading Technology (Intel© HT Technology) | Ja |
| Intel© Quick Sync Video Technology | Ja |
| Intel© My WiFi Technology (Intel© MWT) | Ja |
| Intel© Identity Protection Technology (Intel© IPT) | Ja |
| Energie | |
| Netvoeding | 65 W |
| Eisen aan de omgeving | |
| Temperatuur bij opslag | -20 - 60 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 85 procent |
| Gewicht en omvang | |
| Breedte | 124 mm |
| Diepte | 124 mm |
| Hoogte | 53,7 mm |
| Gewicht | 550 g |
| Gewicht verpakking | 1,4 kg |
| Inhoud van de verpakking | |
| Inclusief monitor | Nee |
| Inclusief muis | Nee |
| Toetsenbord inbegrepen | Nee |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84715000 |
| Warranty | |
| Base Warranty | Non Non |
