Outstanding Visibility with High Reliability
Boasting a high brightness of 3,000 nits, LG's outdoor display, 86XE3FS, captures the attention of passersby even under direct sunlight. Carefully designed to withstand a variety of extreme changes in the environment, the display will stably deliver eye-catching content for as long as you need it to.
High Brightness
With incredibly high brightness at 3,000 nits (Typ.), the 86XE3FS outdoor display delivers contents clearly while captivating passersby, making it the ultimate display for outdoor visibility.
Visible with Polarized Sunglasses
QWP(Quarter Wave Plate) enables clear visibility even when the viewer is wearing polarized sunglasses.
Smart Brightness Compensation
The built-in BLU sensor constantly measures the brightness of the display and automatically compensates for reduced brightness during operation.
Auto Brightness Control
The screen brightness is automatically adjusted depending on the ambient light. The brightness is increased in light for better visibility, while it is decreased in darkness for efficient power management.
Anti-Reflection Coating
AR(Anti-Reflection) Coating has been applied to the 86XE3FS, improving readability by reducing the interference between the display's backlight and reflected external light. Even under direct sunlight or strong lighting, the content still looks clear.
Wide Range of Operating Temperature
The display offers superb reliability under a wide range of operating temperatures, which also goes through LG's solar-loading test which causes a lot of thermal energy. So the 86XE3FS requires fewer constraints for outdoor installations.
Secured Protection with IP56 Design
The display is sealed with IP56 design for reliable operation. It's designed to be not only waterproof but also weatherproof against the damaging effects of the sun, rain, snow, dust and wind, an essential feature for outdoor application.
Electrical Safety
Circuit breaker is inside ensuring absolute protection from overcurrent short circuits, and unwanted voltages. This type of integration establishes preventative solutions for signage's from having future damages.
Protective Glass
The tempered and laminated front glass ensures optimum protection from outdoor extremities, resulting in minimal to no damage from external impacts.
webOS Smart Platform
Quad Core SoC(System-on-Chip) can execute several tasks at the same time without a separate media player. In addition, webOS 3.0 platform enhances user convenience with intuitive UI and simple app development tools.
Web Monitoring
The LG Control Manager, the embedded web monitoring program, allows a variety of parameters to be diagnosed in real time such as temperature, pixel, door, ambient light, and gyro sensors. It can be easily controlled at all times.
| Beeldscherm | |
| Beeldschermdiagonaal | 2,18 m (86") |
| Display technologie | LCD |
| Resolutie | 3840 x 2160 Pixels |
| Helderheid | 3000 cd/mý |
| HD type | 4K Ultra HD |
| Touchscreen | Nee |
| Responstijd | 8 ms |
| Poorten & interfaces | |
| Aantal HDMI-poorten | 1 |
| Aantal HDMI-invoerpoorten | 1 |
| DVI-poort | Ja |
| Aantal DisplayPorts | 1 |
| DisplayPorts in | 1 |
| USB-poort | Ja |
| Ethernet LAN | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten | 2 |
| Wifi | Nee |
| RS-232C | Ja |
| Remote (IR) ingang | 1 |
| Design | |
| Productontwerp | Digitale signage flatscreen |
| Ondersteuning voor plaatsing | Buiten |
| Model | Verticaal |
| Kleur van het product | Zwart |
| VESA-montage | Nee |
| Bezel breedte (onderkant) | 10,1 cm |
| Bezel breedte (zijkant) | 13,5 cm |
| Bezel breedte (bovenkant) | 10,1 cm |
| Antireflectiescherm | Ja |
| Prestatie | |
| Bedoeld voor | Commercieel |
| Bedrijfsuren (uren/dagen) | 24/7 |
| Internationale veiligheidscode (IP) | IP56 |
| Energie | |
| Stroomverbruik (typisch) | 1450 W |
| Stroomverbruik (in standby) | 0,5 W |
| Vermogensverbruik (max) | 1850 W |
| AC-ingangsspanning | 100 - 240 V |
| AC-ingangsfrequentie | 50 - 60 Hz |
| Computersysteem | |
| Inclusief besturingssysteem | WebOS |
| Gewicht en omvang | |
| Schermbreedte | 1338 mm |
| Display diepte | 187 mm |
| Display hoogte | 2100 mm |
| Display gewicht | 276 kg |
| Verpakking | |
| Breedte verpakking | 1503 mm |
| Diepte verpakking | 468 mm |
| Hoogte verpakking | 2296 mm |
| Gewicht verpakking | 310 kg |
| Inhoud van de verpakking | |
| Afstandsbediening inbegrepen | Ja |
| Meegeleverde kabels | HDMI, LAN (RJ-45), Phone, USB |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -30 - 50 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 100 procent |
| Overige specificaties | |
| Audio-ingangen | 1 |
| Warranty | |
| Base Warranty | Non Non |
