The Gryphon 4500 series stands out with an elegant and trendy design, user friendly ergonomics and features the most advanced megapixel sensor with warm-white-illumination 2D technology for outstanding performance.
The Gryphon 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes. High Density (HD) models are available for reading smaller, condensed codes as well as a dedicated version with red illumination optics to support Digital Watermarking.
Datalogic’s Motionix™ motion-sensing technology enables the scanner to intuitively switch into ‘hand held’ mode when the device is picked up. When placed back into the cradle, it seamlessly returns to ‘stand’ mode. The adjustable position cradle provides the flexibility to use the scanner in presentation or stand mode while it is charging.
The wireless models feature Bluetooth wireless technology (GBT model) or narrow band radio communications with Datalogic’s STAR Cordless System (GM model).
One of the most important technical innovations that the Gryphon 4500 wireless readers achieve is the wireless charging system for the battery, which enhances the reliability of the entire solution, while lowering the total cost of ownership (no need for contact cleaning or maintenance procedures). The maximum reliability offered by the Gryphon wireless charging technology means 24/7 activities with no stops for maintenance or repair and top-level operating productivity and performance.
The Gryphon 4500 imagers are also available in Healthcare models featuring disinfectant-ready and anti-microbial enclosures for applications in the Healthcare industry.
| Scannen | |
| Soort | Draagbare streepjescodelezer |
| Soort scanner | 1D/2D |
| Type beeldsensor | Laser |
| Ondersteunde streepjescodes (1D) | Code 39, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional, PDF417, U.P.C. |
| 2D ( matrix en gestapeld ) barcodes ondersteund | Aztec Code, Datamatrix, GS1 DataBar Expanded Stacked, GS1 DataBar Gestapeld Omnidirectioneel, MaxiCode, Micro QR Code, MicroPDF417, QR Code |
| Resolutie optische sensor (WxH) | 1280 x 800 Pixels |
| Licht niveaus (direct zonlicht) | 0 - 100000 Lux |
| Golflengte | 650 nm |
| Tilt lees-hoek | 0 - 360ø |
| Pitch lees-hoek | -65 - 65ø |
| Yaw lees-hoek | -65 - 65ø |
| Poorten & interfaces | |
| Connectiviteitstechnologie | Draadloos |
| Standaard interfaces | RF Draadloos |
| Aansluitbereik | 50 m |
| Frequentie | 433 MHz |
| Prestatie | |
| Internationale veiligheidscode (IP) | IP52 |
| Kleur van het product | Zwart |
| Energie | |
| Type stroombron | Batterij/Accu |
| Batterijtechnologie | Lithium-Ion (Li-Ion) |
| Capaciteit van de accu/batterij | 3250 mAh |
| Accu/Batterij voltage | 12 V |
| Aantal lezingen per inzet | 80000 |
| Oplaadtijd | 4 uur |
| Ingangsspanning | 4.5 - 14 V |
| Gewicht en omvang | |
| Breedte | 109 mm |
| Diepte | 68 mm |
| Hoogte | 166 mm |
| Gewicht | 235 g |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | 0 - 50 øC |
| Temperatuur bij opslag | -40 - 70 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 0 - 95 procent |
| Technische details | |
| Duurzaamheidscertificaten | RoHS |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 84716070 |
| Warranty | |
| Base Warranty | Non Non |
