Product Informatie
Unmanaged Plug and Play
Plug in and go. The DIS-100G-5SW reliably forwards Ethernet frames.
Gigabit Connectivity with SFP slot
Designed with 4 x 100/1000Base-T ports and 1 x 100/1000BaseSFP slot to suit a range of devices and network layouts.
Officially Certified
Certifications for vibration, shock, free-fall, NEMA-TS2 Section 2, and electromagnetic compatibility to maximise network uptime in a variety of deployment environments, including smart city surveillance, factory automation, and outdoor wireless networks.
Withstands Extreme Temperatures
Operates effortlessly in a range of industrial and harsh environments in temperatures from -40°C to +75°C, and can cold start from -40°C.
Strong Build
The tough housing has been created to keep your network protected and reliably rugged. That’s why every DIS-switch comes with a 5-year D-Link warranty.
Fast Deployment
For instant installation it features a snap-to-DIN-rail clip, and also supports wall mounting.
Fanless Design
With no moving parts inside to reduce downtime and maintenance call outs, the rugged housing has been optimised for the transfer of heat.
| Beheerfuncties | |
| Switch type | Managed |
| Quality of Service (QoS) | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 8 |
| Type basis-switching RJ-45 Ethernet-poorten | Gigabit Ethernet (10/100/1000) |
| Aantal moduleslots SPF | 2 |
| Netwerk | |
| Netwerkstandaard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3z |
| Koperen ethernetbekabelingstechnologie | 1000BASE-T |
| Auto MDI/MDI-X | Ja |
| Data-uitwisseling | |
| Switchingcapaciteit | 20 Gbit/s |
| Verzending snelheid | 14,88 Mpps |
| MAC-adrestabel | 4000 entries |
| Store-and-forward | Ja |
| Jumbo Frames ondersteuning | Ja |
| Jumbo frames | 9000 |
| Doorzendmethode | Store-and-forward |
| Design | |
| Rack-montage | Nee |
| Stapelbaar | Ja |
| Kleur van het product | Zwart |
| LED-indicatoren | Activiteit, Link, Stroom |
| Internationale veiligheidscode (IP) | IP40 |
| Certificering | 47 CFR FCC Part 15 Subpart B (Class A), ICES-003 Issue 6 (Class A) EN 61000-4-2 ESD, EN 61000-4-3 RS, EN 61000-4-4 EFT, EN 61000-4-5 Surge, EN 61000-4-6 CS, EN 61000-4-8 IEC 60068-2-27 Shock, IEC 60068-2-32 Freefall, IEC 60068-2-6 Vibration CE, FCC |
| Prestatie | |
| Fanloos | Ja |
| Mean time between failures (MTBF) | 392267 uur |
| Energie | |
| DC voltage input | 12 - 48 V |
| Stroom | 1 A |
| Vermogensverbruik (max) | 7,44 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Nee |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -20 - 65 øC |
| Temperatuur bij opslag | -20 - 85 øC |
| Relatieve vochtigheid in bedrijf (V-V) | 5 - 95 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Gewicht en omvang | |
| Breedte | 190 mm |
| Diepte | 28 mm |
| Hoogte | 100 mm |
| Gewicht | 498 g |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
