Cisco Ie 2000 16port Poe On Lan Basewith 1588 Ge Uplinks
ITCurry #: 0918K217 | Article #: IE-2000-16PTC-G-E-
SchermGeheugenGewichtProcessorHard DiskSSDSchermResolutieConnectiviteitGeheugenDesktopOSSchermTypeSnelheid ZwartSnelheid KleurenModelSnelheidVorm factorInterne / ExterneAantal poortenUplink / mediaMontage
- Alles bekijken
Bundles
Verwante producten
Product Informatie
The Cisco® Industrial Ethernet 2000 (IE 2000) Series is a range of compact, ruggedized access switches that handle security, voice, and video traffic across industrial networks. They provide customers in industries such as automotive, oil and gas, mining, transportation, and energy with highly secure access and industry-leading convergence using Cisco Resilient Ethernet Protocol (REP).
Product Details
The Cisco IE 2000 Series are designed for low cost, low ports, and small sizes. They offer:
- Four, eight, or 16 10/100Base-T Ethernet ports (Small Form-Factor Pluggable [SFP] downlinks on selected models); fixed configurations with a compact form factor
- Two gigabit combo ports: SFP (100 Mbps and 1 Gbps) or RJ45 uplink
- Dual-input DC power supply, alarm relays, DIN rail mount
- Industrial Power over Ethernet (PoE) solution
- Conformal coating available
- Swappable SD flash card and mini-USB connector
- Industrial environmental compliance and certifications
- Industrial partner applications: Ethernet/IP and PROFINET
Primary Benefits and Features
- Easy deployment: Zero-touch discovery using Dynamic Host Control Protocol (DHCP), express setup, and fast bootup time (60 seconds) to help in migrating to an Ethernet environment without resistance.
- Security: 802.1x, port security, and DHCP allow dynamic port-based authentication; Secure Shell (SSHv2); SNMPv3 provides encrypted administrator traffic during Telnet and SNMP sessions; TACACS+ and RADIUS authentication facilitate centralized control and restrict unauthorized users.
- Resiliency: Flex links for fast recovery; Cisco REP protocol for fast convergence.
- Manageability: Auto SmartPort, Web Device Manager, Telnet, HTTPS access, SNMP, CNA, and Cisco Prime Infrastructure 1.2.1.
- Network Address Translation (NAT): Line-rate, hardware-enabled 1:1 static address translation designed to enable duplicate IP address usage in the Layer 2 machine node networks.
- Industrial PoE: PoE (IEEE 802.af) and PoE+ (802.3at) supported on selected models.
- Industrial automation protocols: Common Industrial Protocol (CIP) and PROFINETv2 allow integration with existing management platforms from Rockwell, Siemens, and others.
Product Specifications
Switch Performance and Scalability
- Line-rate, nonblocking uplink, downlink ports
- Forwarding rate: 6.5 Mpps with 64-byte packets
- Egress buffer: 2 MB
- Unicast MAC addresses: 8000
- Internet Group Management Protocol (IGMP) multicast groups: 255
- Maximum virtual LANs (VLANs): 255
- IPv4 MAC security ACEs: 384 (default ternary content-addressable memory [TCAM] template)
- Bidirectional, 128 NAT translation entries
| Beheerfuncties | |
| Switch type | Managed |
| Switch-laag | L2 |
| Quality of Service (QoS) | Ja |
| Web-gebaseerd management | Ja |
| Traffic shaping | Ja |
| ARP-inspectie | Ja |
| System event log | Ja |
| Poorten & interfaces | |
| Aantal basis-switching RJ-45 Ethernet-poorten | 16 |
| Type basis-switching RJ-45 Ethernet-poorten | Fast Ethernet (10/100) |
| Fast Ethernet (koperen) ports kwantiteit | 16 |
| Aantal Combo SFP-poorten | 2 |
| Aantal USB 2.0-poorten | 1 |
| Netstekker | DC-in ingang |
| Netwerk | |
| Netwerkstandaard | IEEE 1588, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| 10G support | Nee |
| Full duplex | Ja |
| IP routing | Ja |
| Verbindingsaggregatie | Ja |
| Broadcast stormbeheer | Ja |
| Rate limiting | Ja |
| Spanning tree protocol | Ja |
| VLAN=ondersteuning | Ja |
| Aantal VLANs | 1005 |
| Data-uitwisseling | |
| Switchingcapaciteit | 7,6 Gbit/s |
| Throughput | 6,5 Mpps |
| Verzending snelheid | 5,66 Mpps |
| MAC-adrestabel | 8000 entries |
| Statische route | Ja |
| Packet buffergeheugen | 2 MB |
| Beveiliging | |
| DHCP-functies | DHCP server, DHCP snooping |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
| Ondersteunde beveiligingsalgoritmen | 802.1x RADIUS, FIPS 140-2, SNMP, SSH-2 |
| MAC adres filtering | Ja |
| SSH/SSL support | Ja |
| BPDU filtering / bescherming | Ja |
| Authenticatie | MAC-gebaseerde authenticatie, Poortgebaseerde authenticatie |
| Multicast-functies | |
| Multicast-ondersteuning | Ja |
| Aantal gefilterde multicast-groepen | 255 |
| Protocollen | |
| Beheerprotocollen | SNMPv3 |
| Design | |
| Kleur van het product | Zwart |
| LED-indicatoren | Ja |
| Veiligheid | UL 60950-1, CSA C22.2 No. 60950-1, EN 60950-1, CB IEC 60950-1, NOM NOM-019-SCF1 |
| Certificering | FCC, IEC/EN 55022A, VCCI, AS/NZS CISPR 22, CISPR 11, CISPR 22, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-64, EN 61373, UL/CSA, CE, AS/NZ RCM, BSMI, KCC, ANATEL, RoHS |
| Prestatie | |
| Intern geheugen | 256 MB |
| Flash memory | 64 MB |
| Energie | |
| AC-ingangsspanning | 110 - 220 V |
| Stroomverbruik (typisch) | 21 W |
| Vermogensverbruik (max) | 30 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Ja |
| Aantal Power over Ethernet plus (PoE +)-poorten | 4 |
| Eisen aan de omgeving | |
| Bedrijfstemperatuur (T-T) | -40 - 70 øC |
| Temperatuur bij opslag | -40 - 85 øC |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Hoogte, in bedrijf | 0 - 4572 m |
| Gewicht en omvang | |
| Breedte | 129,5 mm |
| Diepte | 114,6 mm |
| Hoogte | 127 mm |
| Gewicht | 1,97 kg |
| Logistieke gegevens | |
| Code geharmoniseerd systeem (HS) | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
