Laser Projector LSD400WE DLP WXGA 4000 Lm 3000000:1
ITCurry #: 11914677 | Article #: LSD400WE-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The LSD400WE is part of ViewSonic’s Luminous Superior Series, a lamp-free projector lineup designed for commercial and educational environments. Powered by 3rd-generation laser phosphor technology, it provides 4,000 ANSI Lumens of brightness and an impressive lifespan of up to 30,000 hours. Its lamp-free design ensures eco-friendliness and cost-efficiency by reducing up to 49% power consumption than comparable lamp projectors. Delivering ultra-large projections up to 300” in WXGA resolution, this projector leverages high native contrast from a 0.65” DMD chip with DLP technology. Equipped with a 1.1x optical zoom, H/V keystone & 4 corner correction, and 360° projection, the LSD400WE supports flexible installation options, making it an excellent choice for meeting rooms, classrooms, and golf simulation setups.
Bright, Compact, Durable
The LSD400WE incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods of use.
Clear Visuals for Business and Education Environments
Thanks to the latest laser technology, the LSD400WE achieves high brightness of 4,000 ANSI Lumens. With WXGA resolution?, the projector ensures bright and detailed images in dim or lit environments.
Unmatched Contrasts, Enhanced Visibility
Experience enhanced visuals with the LSD400WE, boasting high contrast thanks to DLP technology and an advanced 0.65" DMD chip from Texas Instruments. This provides deeper blacks and richer depth, ensuring an exceptional viewing experience.
Ultra-Large Screen with Lower Cost-per-Inch
This easy-to-install projector allows for an image size of up to 300”, offering a lower cost-per-inch compared to other types of commercial displays.?
Save on Costs and Energy
With its advanced lamp-free light source, the LSD400WE offers a highly energy-efficient and cost-saving display solution by consuming up to 49% less power than competing projectors.
Reliable Long-Term Performance with DLP Projection Technology?
With DLP technology, the LSD400WE maintains consistent colour performance over time, free from any yellowing issues. Featuring a sealed engine design (IP6X), it is filter-free, preventing dust from affecting internal components and ensuring minimal maintenance. Moreover, it offers crisp and seamless image quality, displaying remarkable contrast and eliminating the noticeable screen-door effect.
Get ??Perfectly-Shaped Images Effortlessly
Horizontal and vertical keystone correction, along with 4-corner adjustment features, eliminate crooked or distorted images for a perfectly proportioned picture every time.
Versatile Creative Application?s
The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.
Brilliant Colours for an Authentic Golf Experience
Powered by ViewSonic’s advanced colour-tuning technology, the projector features a dedicated Golf Mode that enhances colours, especially greens and blues, more vivid and brings fairways and putting surfaces to life with striking realism, creating a golf experience that feels as close to reality as possible.
Upgrade Your Projector with Wireless Content Casting
Enhance your projector with the ViewShare Wireless Screen Casting Kit for seamless wireless content sharing. The projector‘s built-in 5V/1.5A USB-A output powers the dongle, enabling simultaneous multimedia streaming and power charging without adapters. *ViewShare sold separately
A Simpler Way to Update Projector Software
Skip trips to the service center by keeping software up to date easily via USB cable connection with your laptop. This efficient solution, developed exclusively by ViewSonic, ensures optimal performance without the hassle.Learn more: https://youtu.be/irlhJLpDHas*The latest projector software update can be found in the download section at the bottom of the page when available.
| Projector | |
| Smart projector | No |
| Screen size (max) | 7.62 m (300") |
| Screen size compatibility | 762 - 7620 mm (30 - 300") |
| Projection distance | 1 - 11.11 m |
| Projector brightness | 4000 ANSI lumens |
| Projection technology | DLP |
| Projector native resolution | WXGA (1280x800) |
| Contrast ratio (typical) | 3000000:1 |
| Number of colours | 1.07 billion colours |
| Keystone correction, horizontal | +-30ø |
| Keystone correction, vertical | +-30ø |
| Matrix size | 1.65 cm (0.65") |
| Matrix type | DMD |
| Horizontal synchronization (min) | 15 kHz |
| Horizontal synchronization (max) | 102 kHz |
| Vertical synchronization (min) | 0.024 kHz |
| Vertical synchronization (max) | 0.12 kHz |
| Light source | |
| Light source type | Laser |
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Light source brightness | 4800 lm |
| Lens system | |
| Focus | Manual |
| Focal length range | 21.85 - 24 mm |
| Aperture range (F-F) | 2.4 - 2.53 |
| Zoom capability | Yes |
| Digital zoom | 2x |
| Optical zoom | 1.1x |
| Throw ratio | 1.544 - 1.72 |
| Offset | 124% |
| Video | |
| Full HD | Yes |
| 3D | No |
| Supported graphics resolutions | 640 x 480 (VGA), 1920 x 1200 (WUXGA) |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Ports & interfaces | |
| HDMI connector type | Full-size |
| HDMI version | 1.4 |
| USB 2.0 Type-A ports quantity | 1 |
| Serial interface type | RS-232 |
| PC Audio out | Yes |
| HDMI ports quantity | 2 |
| DVI port | No |
| Network | |
| Smart TV | No |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Wi-Fi | No |
| Storage | |
| Card reader integrated | No |
| Features | |
| Noise level (economic mode) | 25 dB |
| HDCP | Yes |
| On Screen Display (OSD) | Yes |
| On Screen Display (OSD) languages | Multi |
| HDCP version | 1.4 |
| Noise level | 30 dB |
| International Protection (IP) code | IP6X |
| Multimedia | |
| Built-in speaker(s) | Yes |
| RMS rated power | 3 W |
| Design | |
| Product type | Standard throw projector |
| Product colour | White |
| Cable lock slot | Yes |
| Display | |
| Built-in display | No |
| Power | |
| Power source | AC |
| Power consumption (typical) | 114 W |
| Power consumption (standby) | 0.5 W |
| AC input voltage | 100 - 240 V |
| AC adapter output voltage | 19.5 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Weight & dimensions | |
| Width | 286 mm |
| Depth | 216 mm |
| Height | 129 mm |
| Weight | 3.1 kg |
| Package width | 400 mm |
| Package depth | 155 mm |
| Package height | 280 mm |
| Package weight | 4.6 kg |
| Packaging content | |
| Remote control included | Yes |
| Cables included | AC |
| AC adapter included | Yes |
| Warranty card | Yes |
| Technical details | |
| Image lag time | 16.7 ms |
| Logistics data | |
| Quantity per pack | 1 pc(s) |
| Pallet gross length | 102 cm |
| Pallet gross width | 122 cm |
| Pallet gross height | 181 cm |
| Products per master (outer) case | 1 pc(s) |
| Harmonized System (HS) code | 8528620000 |
| Warranty | |
| Base Warranty | Non Non |
