Product Information
The wireless bridge can be applied in industries, such as wireless video security, railway, transportation, power and other industries, wireless video/data transmission, wireless coverage, carrier wireless backbone network construction, Wi-Fi wireless coverage, rural information construction, and wireless network coverage. The long-distance transmission of the device can guarantee multi-channel HD video transmission.
| Data transmission | |
| Maximum data transfer rate | 867 Mbit/s |
| Maximum transfer distance | 15000 m |
| Antenna | |
| Antenna design | Internal |
| Antenna gain level (max) | 12 dBi |
| Pan/tilt-axis range | 35ø |
| Wireless LAN features | |
| Wi-Fi | Yes |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| WLAN data transfer rate (max) | 867 Mbit/s |
| Frequency band | 5.15 - 5.85 GHz |
| Signal strength | 22 dBm |
| Receiver sensitivity | -60ñ2 dBm@AC80-MCS9, -86ñ2dBm@AC80-MCS0 |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Ethernet LAN (RJ-45) ports | 2 |
| Security | |
| Security algorithms | WPA2-PSK |
| Security features | NTP, SADP, HTTPS, SSH |
| Management features | |
| Web-based management | Yes |
| Features | |
| Product type | Network bridge |
| Mounting type | Wall |
| Product colour | White |
| LED indicators | LAN, Power, Signal strength |
| Reset button | Yes |
| International Protection (IP) code | IP55 |
| Power | |
| Power source type | DC |
| Power consumption (typical) | 3 W |
| Power consumption (max) | 7.5 W |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 70 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -40 - 85 øC |
| Storage relative humidity (H-H) | 5 - 95% |
| Certificates | |
| Safety | UL (UL 60950-1), CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) |
| Certification | CE-EMC (EN 55032: 2015+A11: 2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014, EN 55035: 2017+A11: 2020),IC (ICES-003: Issue 7:2020),RCM (AS/NZS CISPR 32: 2015) UL (UL 60950-1),CB (AMD1:2009, AMD2:2013, IEC 62368-1: 2014 (Second Edition), CE-LVD (EN 62368-1: 2014+A11: 2017) CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006) EN 301 893,EN 300 440,EN 62311,EN 301 489-3,EN 301 489-17,FCC Part 15.247 |
| Weight & dimensions | |
| Width | 92 mm |
| Depth | 187 mm |
| Height | 58 mm |
| Weight | 307 g |
| Packaging data | |
| Package width | 132 mm |
| Package depth | 91 mm |
| Package height | 228 mm |
| Package weight | 807 g |
| Quantity per pack | 1 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
