Pro Series Network Camera | PTRZ Camera
The PTRZ camera offers a revolutionary dome design that eliminates the need for cover removal. With a transparent cover that allows for adjustments without the hassle of disassembly, this camera streamlines the installation process and reduces the risk of contamination. Additionally, the 5-axis adjustment further equips the PTRZ with day and night lighting compensation capabilities, making it a versatile and reliable security solution.
| Performance | |
| Type | IP security camera |
| Placement supported | Indoor & outdoor |
| Connectivity technology | Wired |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Built-in light | Yes |
| Number of languages | 33 |
| Languages support | Multi |
| Dynamic range | 130 dB |
| Design | |
| Form factor | Bullet |
| Mounting type | Wall |
| Product colour | White |
| Housing material | Metal |
| International Protection (IP) code | IP67 |
| Camera | |
| Minimum illumination | 0 lx |
| Angle of rotation | 360ø |
| Lens viewing angle, horizontal | 111.1ø |
| Lens viewing angle, vertical | 57.6ø |
| Lens viewing angle, diagonal | 138.5ø |
| Tilt angle range | 0 - 90ø |
| Pan range | 0 - 360ø |
| Camera shutter speed | 1 - 1/100000 s |
| Number of Privacy masking areas | 4 |
| Image sensor | |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 1.8 mm (1 / 1.8") |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Lens system | |
| Number of lenses | 1 |
| Detect distance | 61 m |
| Observe distance | 24 m |
| Recognize distance | 12 m |
| Maximum aperture number | 1 |
| Identify distance | 6 m |
| Fixed focal length | 2.8 mm |
| Night vision | |
| Night vision | Yes |
| Night vision distance | 40 m |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Video | |
| Maximum resolution | 2688 x 1520 pixels |
| Total megapixels | 4 MP |
| Video formats supported | H.264, H.264+, H.265, H.265+ |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
| Supported graphics resolutions | 2688 x 1520 |
| Supported video modes | 1520p |
| Video recording | Yes |
| Video streaming | Yes |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Bit rate | 32 Kbps to 8 Mbps |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | No |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Audio formats supported | AAC-LC, G.711 A-law, G.711 æ-law, G.722.1, G.726, MP2L2, MP3 |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Number of microphones | 2 |
| Bit rate range | 8 - 380 Kbit/s |
| Sample rates | 8 - 48 kHz |
| Network | |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Number of users | 32 user(s) |
| User access level | Administrator, Operator, User |
| Live view | Yes |
| Number of simultaneous live view channels | 6 channels |
| Storage | |
| Built-in HDD | No |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Maximum memory card size | 512 GB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Video motion detection | Yes |
| Privacy protection | Yes |
| Anti-flicker | Yes |
| Heartbeat | Yes |
| Mirror | Yes |
| Password reset via email | Yes |
| Pixel counter | Yes |
| Flash log | Yes |
| Human and vehicle targets classification | Yes |
| Audit log | Yes |
| Automatic Network Replenishment (ANR) | Yes |
| Digest authentication | Yes |
| Network access storage (NAS) | Yes |
| Management features | |
| Cloud-managed | Yes |
| Power | |
| Power source type | DC, PoE |
| Power consumption (max) | 12 W |
| Power consumption (Power over Ethernet (PoE)) | 16 W |
| DC output voltage | 12 |
| DC output current | 1 A |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 60 øC |
| Storage temperature (T-T) | -30 - 60 øC |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Weight & dimensions | |
| Diameter | 7.44 cm |
| Length | 176.3 mm |
| Weight | 530 g |
| Packaging data | |
| Package width | 234 mm |
| Package depth | 120 mm |
| Package height | 117 mm |
| Package weight | 815 g |
| Packaging content | |
| Number of cameras | 1 |
| Manual | Yes |
| Warranty | |
| Base Warranty | Non Non |
