Aruba Networking AP-655 (RW) Tri Radio 4x4 802.11ax Wi-Fi 6E Internal Antennas TAA Campus AP
ITCurry #: 1171AMW5 | Article #: R7J43A-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The HPE Aruba Networking 650 Series Campus Access Points are our flagship Wi-Fi 6E access points that take advantage of the 6 GHz band for greater capacity, wider channels and interference-free spectrum. Designed to meet the demands of bandwidth-hungry video, a growing numbers of client and IoT devices, and the growth of cloud services, these high-performance Wi-Fi 6E access points provide comprehensive tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz to deliver up to 7.8 Gbps combined aggregate data rate. The 650 Series access points includes ultra tri-band filtering to help minimize channel interference and dual configurable 5 Gbps Ethernet ports to mitigate coverage gaps, provide greater resiliency, and deliver fast, secure connectivity. Up to seven 160MHz channels in 6 GHz support low-latency, bandwidth-hungry applications such as high-definition video and AR/VR applications. The 650 Series access points include a limited lifetime warranty.
What is new supporting point:
[1] Internet of Things (IoT) ready with support for Bluetooth Low Energy (BLE) and Zigbee.
Patented ultra tri-band (UTB) filtering enhances the use of 5 GHz and 6 GHz bands.
High availability with dual 5 Gbps wired ports for redundant Ethernet and power.
4x4 MIMO radios to deliver peak performance and increased capacity using multi-user (MU-MIMO) and orthogonal frequency-division multiple access (OFDMA) (uplink and downlink for both).
Built-in GPS receivers and intelligent software enable APs to self-locate and act as reference points for more accurate indoor location measurements.
Flagship Wi-Fi 6E access points provide tri-band coverage across 2.4 GHz, 5 GHz, and 6 GHz to deliver up to 7.8 Gbps combined aggregate data rate.
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | Yes |
| Maximum data transfer rate | 7800 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 574 Mbit/s |
| Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
| Maximum data transfer rate (6 GHz) | 4800 Mbit/s |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Frequency band | 2.4 - 7.125 GHz |
| Bandwidth | 160 GHz |
| Networking standards | IEEE 802.11ax |
| Channels quantity | 3 channels |
| Auto MDI/MDI-X | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Spread spectrum method | DSSS |
| VLAN support | Yes |
| Maximal-Ratio Combining (MRC) | Yes |
| Cyclic Delay Diversity (CDD) | Yes |
| Cyclic Shift Diversity (CSD) | Yes |
| Dynamic Frequency Selection (DFS) | Yes |
| Data unit aggregation | A-MPDU, A-MSDU |
| Trusted Platform Module (TPM) | Yes |
| BeamForming | Yes |
| Security | |
| Security algorithms | WPA, WPA2, WPA3 |
| Access Control List (ACL) | Yes |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 1 |
| USB connector type | USB Type-A |
| DC-in jack | Yes |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Design | |
| Product colour | White |
| Reset button | Yes |
| LED indicators | Status, System |
| Antenna | |
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 5.4 dBi |
| Certificates | |
| Certification | None |
| Weight & dimensions | |
| Width | 260 mm |
| Depth | 56 mm |
| Height | 260 mm |
| Weight | 1.8 kg |
| Packaging data | |
| Package width | 285 mm |
| Package depth | 285 mm |
| Package height | 95 mm |
| Package weight | 2.3 kg |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 50 øC |
| Storage temperature (T-T) | -25 - 55 øC |
| Storage relative humidity (H-H) | 10 - 100% |
| Warranty | |
| Base Warranty | Non Non |
