TRIPP LITE CAT6 Straight-Through Modular Shielded In-Line Snap-In Coupler w/90-Degree Down-Angled Port
ITCurry #: 57904899 | Article #: N235-001-SH-D-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Strengthen your high-speed network with the N235-001-SH-D Cat6 Straight-Through Modular Shielded In-Line Snap-In Coupler (F/F). It connects two Cat6 patch cords to create one longer cable. Its keystone design is perfect for convenient feed-through patching when used with a standard data wallplate (such as N042-001-WH). One RJ45 port is angled down at a 90-degree angle for easy installation in hard-to-reach spaces. Built for ultra-fast performance, this is an ideal coupler when setting up premise wiring, telecommunications, data networking and Ethernet connections.
Compatible with all Cat6 cables, the N235-001-SH-D’s protective metal housing is fully shielded to reduce EMI/RFI interference that can damage or degrade data. This coupler features straight-through wiring and 50-µin gold-plated contacts designed to resist corrosion. The N235-001-SH-D is UL-listed and meets all requirements for EIA/TIA Category 6 compliance. It’s also backward compatible with Cat5e and Cat5 LANs.
| Features | |
| Connector(s) | RJ45 (FEMALE) |
| Product colour | Silver |
| Cable standard | Cat6a |
| Connector contacts plating | Gold |
| Connector shielding | Yes |
| Certification | TAA |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 60 øC |
| Storage temperature (T-T) | -40 - 68 øC |
| Packaging data | |
| Package width | 101.6 mm |
| Package depth | 12.7 mm |
| Package height | 127 mm |
| Package weight | 20 g |
| Technical details | |
| Interface type | RJ45 (FEMALE) |
| Ports quantity | 2 |
| Logistics data | |
| Country of origin | Taiwan |
| Master (outer) case GTIN (EAN/UPC) | 10037332197204 |
| Master (outer) case width | 132.1 mm |
| Master (outer) case length | 297.2 mm |
| Master (outer) case height | 76.2 mm |
| Master (outer) case gross weight | 730 g |
| Products per master (outer) case | 50 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
