Patch cable - CAT6a - S/FTP - Snagless - Cu - 3m - grey
ITCurry #: M9234805 | Article #: DK-1644-A-030-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Future-oriented standards and high-end quality for your network.
- With an LSZH (Low Smoke Zero Halogen) outer jacket for optimal fire resistance and low smoke emission.
- Transparent yellow-colored connector with metal shielding for easy identification of Category 6A (500 MHz)
- Inner conductor: Copper (Cu)
- Supports: PoE, PoE+, PoE++ (IEEE 802.3af; 3at; bt)
The new DIGITUS patch cable series is being launched with a redesigned connector. The kink-resistant sleeve with latch protection prevents the cables from getting snagged and also protects the latch from breaking off. The connectors are color-coded by category: a blue connector for CAT5e, a red connector for CAT6, and a yellow connector for CAT6A. We also offer a wide variety of lengths and colors to meet every need.
| Features | |
| Product colour | Grey |
| Cable length | 3 m |
| Cable standard | Cat6a |
| Cable shielding | S/FTP (S-STP) |
| Connector 1 | RJ-45 |
| Connector 2 | RJ-45 |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector shield material | Metal foil |
| Jacket material | Low smoke zero halogen (LSZH) |
| Cable shape | Round |
| Conductor type | Stranded |
| Conductor material | Copper |
| Twisted pair coupling type | 4x2 |
| AWG wire size | 26/7 |
| Frequency | 500 MHz |
| Country of origin | China |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 60 øC |
| Certificates | |
| Certification | IEC 60332-1, IEC 60332-3, IEC 61034 |
| Packaging data | |
| Package width | 170 mm |
| Package depth | 18 mm |
| Package height | 250 mm |
| Package weight | 120 g |
| Package volume | 765 cmü |
| Package type | Polybag |
| Other features | |
| Quantity | 1 |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
| UK Trade Tariff code | 85444210 |
| Technical details | |
| Shielding type | Foil + braiding |
| Warranty | |
| Base Warranty | Non Non |
