Fiber optic steel-armored patch cable - simplex singlemode LC/APC - LC/APC - 20m
ITCurry #: M9239739 | Article #: DK-2933A-20-LCA-SX-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The steel-armored fiber optic patch cable offers excellent protection against physical damage, a long service life and low signal loss, making it ideal for harsh environments and high-performance FTTH networks.
- Compact and flexible design
- Improved mechanical strength
- Reliable signal transmission
- Ideal for harsh environments
An armored patch cable is a high-performance fiber optic cable designed for superior durability, enhanced protection and reliable signal transmission in various demanding environments. Unlike standard fiber optic cables, the armored version has a protective layer that shields the delicate fiber core from mechanical stress and external hazards such as crushing, bending and rodent damage. Despite the armoring, the cable remains relatively light and flexible, making it easier to lay and install in tight spaces. It is ideal for FTTH, industrial automation and enterprise network applications. It is the perfect choice when both protection and performance are important, providing a robust yet flexible solution for high-speed fiber optic networks.
| Features | |
| Cable length | 20 m |
| Fibre optic type | G.657.A2 |
| Cable shape | Round |
| Connector 1 | LC |
| Connector 2 | LC |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector polish type | APC |
| Cable type | LC/APC |
| Product colour | Green, White |
| Core diameter | 9 æm |
| Cladding diameter | 125 æm |
| Fiber mode structure | Single-mode |
| Wavelengths supported | 1310 nm |
| Insertion loss | 0.3 dB |
| Return loss | 60 dB |
| Jacket material | Low smoke zero halogen (LSZH) |
| Plug and Play | Yes |
| Operational conditions | |
| Operating temperature (T-T) | -25 - 70 øC |
| Storage temperature (T-T) | -25 - 70 øC |
| Weight & dimensions | |
| Cable diameter | 3 mm |
| Packaging data | |
| Package width | 255 mm |
| Package depth | 255 mm |
| Package height | 26 mm |
| Package weight | 630 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
