4K HDMI Extender Set, HDBaseT 70 m over network cable (Cat 5E, 6, 7) UHD 4K2K/30 Hz
ITCurry #: M9236600 | Article #: DS-55500-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Extends the maximum length for HDMI cables to up to 70m whereby only a simple network cable is used between a sender and a receiver unit
- Extends the maximum length for HDMI cables to up to 70m whereby only a simple network cable is used between a sender and a receiver unit
- Extends 4K video contents to up to 40m with a CAT 6 cable
- Offers simple and quick distribution for HDMI video signals - position your monitors wherever you wish
- Supports 4K Ultra HD (30Hz), 4096 x 2160p resolution
- Uses HDBaseT™ technology
The DIGITUS 4K extender set, HDBaseT™ offers an extender solution up to 70m for the highest demands - for both high definition graphic display and also for absolutely fluent video playback. It transmits digital and audio signals up to a maximum distance of up to 70m. 4K content can be transmitted over up to 40m using a CAT 6 network cable. It consists of a transmitter as well as a receiver unit. Two bi-directional infrared units (sender, receiver) are also supplied, by means of which the remote control of the connected input source can be used.
| Features | |
| Type | AV transmitter & receiver |
| Maximum resolution | 4096 x 2160 pixels |
| Cable types supported | Cat5e, Cat6, Cat6a, Cat7 |
| Maximum transfer distance | 40 m |
| Maximum refresh rate | 60 Hz |
| LED indicators | Yes |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160p |
| Audio formats supported | LPCM |
| HDCP | Yes |
| Material | Metal |
| 3D | Yes |
| Product colour | Black |
| Ports & interfaces | |
| HDBaseT port | Yes |
| HDMI in | 1 |
| Number of HDMI outputs | 1 |
| Remote (IR) input | 1 |
| Remote (IR) output | 1 |
| DC-in jack | Yes |
| Power | |
| Output current | 2 A |
| Power consumption (typical) | 8 W |
| Power over Ethernet (PoE) | No |
| Weight & dimensions | |
| Dimensions (WxDxH) | 66.5 x 98.5 x 23 mm |
| Packaging data | |
| Package width | 149 mm |
| Package depth | 199 mm |
| Package weight | 896 g |
| Packaging content | |
| Manual | Yes |
| Mounting kit | Yes |
| Technical details | |
| Country of origin | China |
| Package volume | 2372.08 cmü |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Warranty | |
| Base Warranty | Non Non |
