Wireless 9172i W7 3 Radio 3 Band 2x2
ITCurry #: 0918AD90 | Article #: CW9172I-RTG-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Product overview
The Cisco Wireless 9172 Series Wi-Fi 7 access points are high-performance wireless solutions designed for environments like boutique hotels, healthcare clinics, retail stores, student housing, and distributed business locations such as regional branches and logistics hubs. With tri-radio functionality across 2.4-GHz, 5-GHz, and 6-GHz bands, the 9172 Series provides reliable, high-speed connectivity (frame rate up to 9000 Mbps) for spaces with low to moderate device density. Flexible deployment options—cloud, on-premises, or hybrid—allow seamless integration into existing networks.
These access points are designed to enhance wireless performance and enable smarter spaces. The 9172H model is tailored for hospitality and multi-dwelling environments, offering additional LAN ports for wired devices and Bluetooth Low Energy (BLE) IoT capabilities for smart room automation. The 9172I model supports flexible configurations, including a high-density 4x4 radio option for 5 GHz when the 6-GHz band is disabled, making it ideal for retail, healthcare, and branch office use. Both models feature plug-and-play setup with mount compatibility for quick and efficient deployment.
For customers, the 9172 Series delivers reliable Wi-Fi 7 performance, enabling advanced applications like IoT integration, telehealth, and seamless customer experiences. The primary business benefit is future-ready connectivity with energy efficiency, reducing power consumption while supporting evolving network demands. This makes the 9172 Series a cornerstone for modernizing and optimizing network infrastructure.
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| 6 GHz | Yes |
| Maximum data transfer rate | 9000 Mbit/s |
| Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
| Networking standards | IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11be, IEEE 802.11n |
| Bluetooth | Yes |
| Bluetooth version | 5.3 |
| Bluetooth Low Energy (BLE) | Yes |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Spread spectrum method | OFDMA |
| Band steering | Yes |
| BeamForming | Yes |
| Receiver sensitivity | 2.4 GHz, 5 GHz, 6 GHz or 2.4 GHz + 5 GHz (4x4:4) |
| Security | |
| Security algorithms | EAP, WPA2, WPA3 |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 1 |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Power consumption (typical) | 30 W |
| Design | |
| Placement | Ceiling, Wall |
| Product colour | White |
| Antenna | |
| Antenna type | Internal |
| Antenna direction type | Omni-directional |
| Antenna gain level (max) | 6 dBi |
| Performance | |
| Flash memory | 16000 MB |
| Internal memory | 4096 MB |
| Weight & dimensions | |
| Width | 200 mm |
| Depth | 200 mm |
| Height | 53 mm |
| Weight | 874 g |
| Packaging content | |
| Quantity per pack | 1 pc(s) |
| Quick start guide | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 øC |
| Storage temperature (T-T) | -30 - 70 øC |
| Warranty | |
| Base Warranty | Non Non |
