Cisco Catalyst 9130ax Series
ITCurry #: 0918V471 | Article #: C9130AXI-A-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
With the emergence of high-density networks and the Internet of Things (IoT), we are more dependent on wireless networks than ever before. Increasing numbers of devices connect to the network every year, ranging from high-performance client devices to low-bandwidth IoT devices. Cisco Catalyst 9130 Series Access Points provide a seamless experience anywhere for everyone, with high scaling and unmatched performance in diverse network deployments. Going beyond the Wi-Fi 6 (802.11 ax) standard, the 9130 Series provides integrated security, resiliency, and operational flexibility as well as increased network intelligence.
Extending Cisco’s intent-based network and perfect for networks of all sizes, the Cisco Catalyst 9130 Series scales to meet the growing demands of IoT while fully supporting the latest innovations and new technologies. The 9130 Series is also a leader in performance, security, and analytics.
The Cisco Catalyst 9130 Series Access Points, paired with the Cisco Digital Network Architecture (Cisco DNA), are enterprise-class products that will address both your current and future needs. They are the first step in updating your network to take better advantage of all of the features and benefits that Wi-Fi 6 provides.
| Features | |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Ethernet LAN data rates | 100,1000,2500,5000 Mbit/s |
| Frequency band | 2.4/5 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Maximal-Ratio Combining (MRC) | Yes |
| Security | |
| Security algorithms | AES, WPA2, WPA3 |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 1 |
| Power | |
| Power over Ethernet (PoE) | Yes |
| Design | |
| Product colour | Grey |
| Antenna | |
| Antenna type | Internal |
| Performance | |
| Flash memory | 1024 MB |
| Internal memory | 2048 MB |
| Weight & dimensions | |
| Width | 226 mm |
| Depth | 226 mm |
| Height | 48 mm |
| Weight | 1.71 kg |
| Warranty | |
| Base Warranty | Non Non |
| Packaging content | |
| Number of products included | 1 pc(s) |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 50 øC |
| Storage temperature (T-T) | -30 - 70 øC |
| Operating altitude | 0 - 3000 m |
