Product Information
Adding a new entry-level 4-inch (114 mm) printing solution to BIXOLON's industrial label printer lineup, XT3-40 is designed with a familiar feel to the XT5-40 Series. The XT3-40 supports fast data processing and print speeds of up to 8 ips (203 mm/sec) at 203 dpi. Featuring a compact and robust design, double-holding door, and side-loading supplier path, the XT3-40 allows easy printer installation within narrow environments.
User-Friendly Design
- Compact and robust design
- Rugged all-metal case and double folding door
- Side-loading supplies path for simplified media and ribbon installation
- 2.4 inch full colour LCD display
- Peeler and Auto Cutter, and factory-installed Rewinder with Peeler options
- Toolless maintenance of roller and print head
- Supporting up to 450 m ribbon length
Industrial-Standard Performance
- Fast data processing and print speeds of up to 8 ips (203 mm/sec)
- Optional 203 or 300 dpi high resolutions
- Fully compatible with market-leading programming languages
- Dual-band WLAN (5 GHz and 2.4 GHz) and Bluetooth V5.2 (MFi certified)
Secure and Efficient Management
- Twin funtion™ supported: Copy printer settings and data via USB
- Compatible with label design software;
- BIXOLON’s Label Artist and Seagull's BarTender
- XPM™ & XCM™ - Web-based printer management software and connection app.
| Printing | |
| Print technology | Thermal transfer |
| Maximum resolution | 203 x 203 DPI |
| Print speed | 203 mm/sec |
| Maximum printing width | 10.8 cm |
| Minimum print length | 4 m |
| Paper handling | |
| Ribbon width | 11 cm |
| Ribbon length | 450 m |
| Maximum label width | 11.4 cm |
| Maximum roll diameter | 20.3 cm |
| Media thickness | 0.06 - 0.25 mm |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| USB port | Yes |
| RS-232 ports | 1 |
| Performance | |
| Page description languages | BPL, SLCS |
| Internal memory | 128 MB |
| Flash memory | 128 MB |
| Built-in barcodes | 1D, 2D |
| Design | |
| Product colour | Black |
| Built-in display | Yes |
| Display | LCD |
| Display diagonal | 6.1 cm (2.4") |
| Colour display | Yes |
| Control type | Buttons |
| Power | |
| AC input voltage | 100-240 V |
| AC input frequency | 50-60 Hz |
| System requirements | |
| Windows operating systems supported | Yes |
| Mac operating systems supported | Yes |
| Mobile operating systems supported | Android, iOS |
| Linux operating systems supported | Yes |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Weight & dimensions | |
| Width | 240 mm |
| Depth | 430.5 mm |
| Height | 276.7 mm |
| Weight | 9.3 kg |
| Packaging content | |
| Cables included | USB |
| Warranty | |
| Base Warranty | Non Non |
