Cpu Adapter/console/divers All-in-one Over Ip Control Unit (KVM + Serial + Power. With Virtual Media
ITCurry #: 90313884 | Article #: KN1000A-AX-G-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
ATEN's new KN1000A Single Port KVM over IP Switch provides access and control “over-IP" for conventional KVM switches and servers that do not have built-in over-IP functionality. It allows system operators to monitor and access computers from remote locations for "down to the BIOS-level" troubleshooting, using standard Web browsers or Windows and Java based application programs, without the need to be on site for constant IT maintenance. In addition, the KN1000A supports out-of-band access in case the LAN goes down, with external modem support as backup.
1 x KN1000A Single Port KVM over IP Switch
1 x 2L-5301UP Custom KVM Cable Sets
1 x LIN5-27X6-U21G Custom Console Cable Set
1 x LIN6-04U1-M18G Mini USB to Type A USB Cable
1 x 0AD8-1605-24M1 Power Adapter
1 x LIN2-418K-P13G Outlet Power Cord
1 x Mounting Kit
1 x User Instructions
| Ports & interfaces | |
| Number of computers controlled | 1 |
| Keyboard port type | No |
| Mouse port type | No |
| Video port type | VGA |
| Console ports | SPHD, USB B |
| USB connector type | Mini-USB B |
| DC-in jack | Yes |
| Network | |
| Ethernet LAN | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
| Performance | |
| HD type | WUXGA |
| Maximum resolution | 1920 x 1200 pixels |
| DDC2B support | Yes |
| Number of users | 54 user(s) |
| Design | |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Yes |
| Display | |
| Built-in display | No |
| Power | |
| Power source | AC |
| Input voltage | H”g videouppl”sning - upp till 1920 x 1200 vid 60 Hz med 24-bitars f„rgdjup f”r den lokala konsolen; upp till 1920 x 1200 vid 60 Hz med 24-bitars f„rgdjup f”r fj„rrsessioner Notera: * Kompatibla KVM-switchar inkluderar f”ljande: CS9134, CS9138, CS1308, CS1316, CS1754, CS1758, CS1708A, CS1716A, ACS1208A, ACS1216A, KH2508A, KH2516A, KH1508A och KH1516A (vissa av funktionerna i KN1000A kanske inte st”ds, beroende p† funktionaliteten i den anslutna KVM-switchen. Till exempel st”djer inte alla switchar virtuell media). Vissa funktioner i de anslutna KVM-switcharna kanske inte st”ds i KN1000A. (Till exempel ljudet i CS1754.) ** Kr„ver en CV130A-converter St”djer TLS 1.2-datakryptering och 2048 bitars RSA-certifikat f”r att s„kra anv„ndarinloggningar som sker via webbl„sare St”d f”r virtuell media |
| AC input frequency | 50 - 60 Hz |
| Input current | 10 A |
| Output voltage | 100 - 240 V |
| Output current | 9 A |
| Sustainability | |
| Compliance certificates | RoHS |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 50 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 83.9 mm |
| Depth | 310 mm |
| Height | 42 mm |
| Weight | 1.61 kg |
| Packaging data | |
| Package width | 207 mm |
| Package depth | 414 mm |
| Package height | 117 mm |
| Package weight | 2.03 kg |
| Logistics data | |
| Master (outer) case net weight | 4.84 kg |
| Harmonized System (HS) code | 85176200 |
| Master (outer) case width | 370 mm |
| Master (outer) case length | 427 mm |
| Master (outer) case height | 232 mm |
| Master (outer) case gross weight | 6.89 kg |
| Products per master (outer) case | 3 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
