Smart UPS 1000va USB & Serial Rm 2u 230v
ITCurry #: 02802730 | Article #: SUA1000RMI2U-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Boost and Trim Automatic Voltage Regulation (AVR)
Gives higher application availability by correcting low and high voltage conditions without using the battery.
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Cold-start capable
Provides temporary battery power when the utility power is out.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Network manageable
Provides remote management of the UPS over the network.
Audible alarms
Actively let you know if the unit is on battery, if the battery is low or if there is an overload condition.
LED status indicators
Quickly understand unit and power status with visual indicators.
Serial Connectivity
Provides management of the UPS via a serial port.
USB connectivity
Provides management of the UPS via a USB port (not available on all models).
Disconnected battery notification
Warns when a battery is not available to provide backup power.
InfraStruXure Manager Compatible
Enables centralized management via the APC InfraStruXure® Manager.
User-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR).
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced.
Predictive failure notification
Provides early-warning fault analysis ensuring proactive component replacement.
Adjustable voltage-transfer points
Maximizes useful battery life by widening the input voltage window or tightening the output voltage regulation.
Adjustable voltage sensitivity
Provides the ability to adapt the UPS for optimal performance in specific power environments or generator applications.
Field-replaceable power distribution panel
Ensures compatibility with equipment that has different plug types.
Resettable circuit breakers
Enables a quick recovery from overload events.
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment. UL, FCC, CE, C-Tick approvals.
| Features | |
| Output power capacity | 1 kVA |
| Output power | 670 W |
| Surge energy rating | 480 J |
| Emergency Power Off (EPO) | Yes |
| Noise level | 36 dB |
| Audible alarm(s) | Yes |
| Ports & interfaces | |
| Number of output IEC jumpers | 2 |
| Battery | |
| Typical backup time at full load | 9.1 min |
| Typical backup time at half load | 31.6 min |
| Battery recharge time | 3 h |
| Hot-swap battery | Yes |
| Replacement battery cartridge | RBC23 |
| Design | |
| Product colour | Black |
| Certification | C-tick,EN 50091-1,EN 50091-2,GOST,VDE |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -15 - 45 øC |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Weight & dimensions | |
| Weight | 28.2 kg |
| Package weight | 31.4 kg |
| Packaging data | |
| Bundled software | - PowerChute Business Edition v6.2.2 Agent f Linux - PowerChute Business Edition v6.2.2 f Netware 5.1/6.0 - PowerChute Business Edition v6.2.2 f XP / 2000 / NT(Sp6 or higher) - 5 Node - PowerChute Business Editon v6.0.2 f Solaris 8.0 |
| Logistics data | |
| Products per pallet | 16 pc(s) |
| Other features | |
| I/O ports | USB |
| Interface | DB-9 RS-232, SmartSlot |
| Input connection type | IEC-320 C14 |
| Dimensions (WxDxH) | 482.6 x 457.2 x 88.9 mm |
| Nominal output voltage | 230 V |
| Nominal input voltage | 230 V |
| Package dimensions (WxDxH) | 594 x 603 x 254 mm |
